Dell R740xd | ▪ 2U Rackmount ▪ 12x front LFF / 4x internal LFF / 4x rear SFF ▪ 1x Low, 3x High PCIe slot |
![]() |
▪ Dual processor support ▪ Xeon Scalable ▪ 24 DDR4 DIMM slots ▪ No Onboard NIC |
![]() |
▪ 2x Gold 6150 ▪ Base 2.7 GHz / Max Turbo: 3.7 Ghz ▪ 18 Cores / 36 Threads ▪ TDP 165 W |
![]() |
▪ 256GB DDR4 ECC-Registered ▪ 16x 16GB PC4-2666V |
![]() |
▪ 12x 4TB 7.2K SAS HDD *² |
![]() |
▪ PERC H740P NV Cache, Mini-Type |
![]() |
▪ 1G BASE-T/10G SFP+ rNDC (with no SFPs) |
![]() |
▪ BOSS.S1 card (2x 240GB M.2 SATA ) |
![]() |
▪ TPM module - none |
![]() |
▪ Remote Access - iDrac Enterprise |
![]() |
▪ IDSDM module - none |
![]() |
▪ Dual 1100W PSU |
![]() |
▪ Optical drive - n/a |
![]() |
▪ Flex bay- Yes *¹ |
![]() |
▪ Rails included |
![]() |
▪ Bezel - none |
![]() |
▪ Used, may have minor marks or scratches |
Notes | *¹ No rear caddies included *² ▪ Drive caddy labels may vary or be missing ▪ Due to the weight of the item, some drives may ship in a separate box. |
(4432)
The PowerEdge R740xd delivers a perfect balance between storage scalability and performance. The 2U two-socket platform is ideal for software-defined storage, service providers, or as virtual desktop infrastructure.
The R740xd versatility is highlighted by the ability to mix any drive type to create the optimum configuration of NVMe, SSD, and HDD for performance, capacity, or both. The R740xd is the platform of choice for software-defined storage and is the foundation for ScaleIO, VSAN, or the PowerEdge XC.
