|Part Number||764618-001, 764737-001, 764285-B21|
|Data Link Protocol||10 GigE, InfiniBand, 40 Gigabit LAN|
|Data Transfer Rate||40 Gbps|
|Number of Ports||2 x 40Gb Ethernet / InfiniBand FDR - QSFP|
|Transceiver Modules||None included|
|Thermal Solution||Passive (fanless heatsink)|
|Compatibility||HPE ProLiant DL Series: Gen9/ Gen10
HPE ProLiant XL Series: Gen9/ Gen10
HPE StoreEasy 1850, 3850 Gateway Single Node
|Key Features||InfiniBand FDR Link support|
The HPE InfiniBand FDR/EN Adapters are designed for customers who need low latency and high bandwidth for high-performance computing (HPC) systems with their HPE ProLiant XL and DL server families in the data center. Based on Mellanox ConnectX-3 PRO, Connect-IB, and ConnectX-5 technology for scalability and fabric flexibility, the dual-ported card can function as a dual-port FDR InfiniBand card, a dual-port Ethernet card, or a mixed-function card. Combined with HPE FDR InfiniBand Switches or Ethernet Switches, they deliver low latency and up to 50 Gb/s bandwidth. Ideal for performance-driven server and storage clustering applications in HPC and enterprise data centers.
Dual-function FDR InfiniBand and 40/50 Gb Ethernet adapter for HPE ProLiant XL and DL Servers
The HPE InfiniBand FDR/EN 2-Port Adapters deliver up to 50 Gbps bandwidth and a sub-microsecond low latency for demanding high-performance computing (HPC) workloads.
The 764285-B21 Ethernet Adapter includes offload engines that speed communications by delivering a low CPU overhead for increasing throughput. It provides the support of remote direct memory access (RDMA) over Converged Ethernet (RoCE) technology that enables efficient low-latency RDMA services over Layer 2 and Layer 3 networks.
