Brand | QNAP |
Type | Network-attached storage (NAS) |
Form Factor | Desktop |
Rails | n/a |
Model | TS-1677X |
Processor | ▪ AMD Ryzen 7 1700 ▪ 8C/16T 3GHz (Turbo: 3.7GHz) |
System Memory | 64GB (4x 16GB) |
Memory Slots | 4x U-DIMM DDR4 |
Drive Bays | 12 x 3.5-inch + 4 x 2.5-inch SATA 6Gb/s, 3Gb/s |
Installed Drives | None (Caddies included) *¹ |
M.2 Slot | None *² |
Flash Memory | Included (for OS) |
Networking | ▪ 4 x 1GbE (RJ45) ▪ 2 x 10GbE (RJ45) |
Adapter | None |
PCIe Slot | 2 |
External ports | ▪ 8x USB 3.2 Gen1 port ▪ 1 x built-in speaker ▪ 2 x 3.5 mm dynamic microphone jacks ▪ 1 x 3.5mm line out jack (for amplifiers or speakers) |
Power Supply | Internal 550W |
Management | Web interface |
Supported RAID | ▪ JBOD, Single ▪ RAID 0, RAID 1 ▪ RAID 5, RAID 6, RAID 10 ▪ RAID 50, RAID 60 |
Size/ Weight | ▪ 30.3 x 36.9 x 31.9 cm (HxWxD) ▪ Chassis only about 15Kg |
Item Condition | Used, has minor marks/ scratches |
Notes | *¹ ▪ No HDD/SSDs ▪ Caddies included w/ no screws *² ▪ M.2 Optional via PCIe adapter - not included |
